Hajji Weldingsupplies is a reputable manufacturer and supplier of cutting-edge welding consumables, proudly based in Tunis, Tunisia. They cater to the fabrication and heavy industry markets both locally and internationally. With a strong dedication to upholding international quality standards and ensuring process reliability, the company specializes in providing comprehensive submerged arc welding solutions. Hajji Weldingsupplies features AWS Class ER308/308H SAW wire paired with compatible flux systems, all designed to guarantee consistent weld quality, high productivity, and outstanding metallurgical performance. With a foundation built on technical expertise, state-of-the-art manufacturing facilities, and attentive customer support, the company delivers reliable solutions for large-scale and critical welding projects.
Table of Contents
AWS Class ER308/308H SAW/Flux Welding Wire Tunisia, Industrial ER308/308H SAW Wire & Flux Tunis, AWS Class ER308/308H Welding Fluxes and Wires Sfax, AWS/ASME 5.9 ER308/308H SAW & Flux Sousse, Alloy 308/308H Welding SAW & Flux Bizerte, UNS S30880 SAW and Flux Tunis, SFA A5.9 ER308/308H SAW & Flux Sfax, AWS ER308/308H SAW & Flux Wire Tunis, AWS Class ER308/308H SAW & Flux Supplier in Tunisia, Tunis.
AWS Class ER308/308H SAW & Flux Specification
| Classification | AWS A5.9, ER308/308H |
| Form | Welding Fluxes and Wires |
| Type Of Welding | Submerged Arc Welding |
| Thickness available | Upto 4 mm |
| AWS ER308/308H SAW & Flux Application & uses |
|
What is AWS Class ER308/308H SAW & Flux?
The AWS Class ER308/308H SAW wire is an austenitic stainless steel filler metal that boasts a balanced mix of chromium and nickel. The 308H grade, in particular, has a higher carbon content, enhancing its strength at elevated temperatures. When paired with the right flux, this system offers stable arc characteristics, easy slag removal, and clean weld beads. The weld metal produced shows impressive tensile and yield strength, excellent toughness, and dependable ductility. These mechanical properties help prevent hot cracking, ensure sound weld integrity, and maintain stable performance in both regular and high-temperature conditions.
AWS Class ER308/308H SAW & Flux Chemical Composition
| C | Mn | Si | Cr | Ni | S | P | Mo | Cu |
| 0.04-0.08 | 1.0-2.5 | 0.30-0.65 | 19.5-22.0 | 9.0-11.0 | 0.03 | 0.03 | 0.50 | 0.75 |
AWS Class ER308/308H SAW & Flux Minimal Mechanical Properties
| Tensile Strength | 86,500 psi |
|---|---|
| Yield Strength | 57,500 psi |
| Elongation (%) | 39% |
Equivalent AWS Class ER308/308H SAW & Flux
| Diameter | Amperage | Volts | Shielding Gas | |
| GTAW | 1/16” | 80-110 | 100% Ar | |
| 3/32” | 90-130 | |||
| 1/8” | 120-175 | |||
| 5/32” | 150-220 | |||
| GMAW Spray Transfer | .030” | 130-200 | 23-27 | 98% Ar/ 2% O2 (35 cfh) |
| .035” | 150-225 | 23-26 | ||
| .045” | 200-325 | 24-28 | ||
| 1/16” | 300-350 | 24-27 | ||
| GMAW Short-Circuit | .030” | 50-150 | 14-20 | 90% He/ 7½% Ar/ 2½% CO2 (25 cfh) |
| .035” | 60-200 | 14-22 | ||
| .045” | 75-225 | 15-23 | ||
| 1/16” | 100-250 | 16-23 | ||
| SAW | 3/32” | 275-350 | 28-30 | Suitable Flux |
| 1/8” | 350-450 | 29-32 |
AWS Class ER308/308H SAW & Flux Exporters Tunisia, AWS Class ER308/308H Submerged Arc Welding Wire Tunis, AWS Class ER308/308H Submerged Arc Welding Flux Sfax, Alloy 308/308H SAW & Flux Stockist Sousse, AWS A5.9 ER308/308H SAW & Flux Welding Wire Bizerte, AWS Class ER308/308H SAW & Flux Stockist in Tunis, Sfax.
Leading Industrial Supplier of AWS Class ER308/308H SAW & Flux For Welding Solutions in Tunis
At Hajji Welding Supplies, we take pride in being one of Tunis’s trusted suppliers of high-quality welding consumables. Our expertise lies in AWS Class ER308/308H SAW & Flux, engineered for precision, durability, and resistance to corrosion. With a strong commitment to quality and customer satisfaction, we provide welding solutions that support industries across construction, energy, shipbuilding, and manufacturing.
ISO Certified
Largest Inventory
On Time Deliveries
Customer Support
AWS Class ER308/308H SAW/Flux Welding Wire Tunisia, Industrial ER308/308H SAW Wire & Flux Tunis, AWS Class ER308/308H Welding Fluxes and Wires Sfax, AWS/ASME 5.9 ER308/308H SAW & Flux Sousse, Alloy 308/308H Welding SAW & Flux Bizerte, UNS S30880 SAW and Flux Tunis, SFA A5.9 ER308/308H SAW & Flux Sfax, AWS ER308/308H SAW & Flux Wire Tunis, AWS Class ER308/308H SAW & Flux Supplier in Tunisia, Tunis.
Types of AWS Class ER308/308H SAW & Flux
AWS Class ER308/308H SAW & Flux Uses
AWS Class ER308/308H SAW & Flux systems are commonly utilized for welding 304 and 304H stainless steels in applications like pressure vessels, storage tanks, pipelines, and structural fabrications. They shine in high-deposition welding of thick sections, particularly in industries such as chemical processing, petrochemical plants, power generation, and food processing. This combination is perfect for projects that demand high productivity, consistent weld quality, and reliable corrosion resistance, making it a top choice for both automated and semi-automated submerged arc welding operations in heavy industrial manufacturing.
