Home > MIG and TIG > AWS Class ER316/316H MIG and TIG
Hajji Welding Supplies is a company located in Tunisia, Tunis that produces and supplies AWS Class ER316/316H MIG and TIG filler welding wires and rods. Our products have been designed to produce high-temperature strength, outstanding corrosion protection and consistent mechanical operation, particularly in high chloride or chemical environments, when welding austenitic stainless steel that has molybdenum. Hajji Welding Supplies has state-of-the-art production facilities and a stringent quality control measure that has provided a good amount of consistency and quality in its welds, thus, making it a dependable and acceptable quality of welds in industries and businesses. Our ER316/316H wires and rods are ideal in chemical processing, petrochemical, marine, and power generation plants and are designed to provide a durable, smooth and defect-free weld joint to meet the most challenging requirements.
| Classification | AWS A5.9, ER316/316H |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Current | MIG-DCEP / TIG-DCEN |
| Diameters | .023”, .030”, .035”, .045”, 1/16”, 3/32”, 1/8” |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ER316/316H MIG & TIG Filler Metal Application & uses |
|
Hajji Weldingsupplies is a trusted manufacturer and supplier located in Tunis, Tunisia, specializing in top-notch welding consumables that meet international standards. They provide AWS Class ER316/316H MIG and TIG filler wires, which are specifically designed for precision welding in challenging environments that involve corrosion and high temperatures. With a strong commitment to metallurgical consistency, product reliability, and customer satisfaction, Hajji Weldingsupplies caters to various industries, including petrochemical, oil and gas, power generation, marine, and food processing. Thanks to their modern manufacturing facilities and rigorous quality control systems, the company guarantees dependable weld performance and a long service life for critical applications.
Hajji Welding Supplies Tunis
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
| 0.03 | 18.0-20.0 | 11.0-14.0 | 2.0-3.0 | 1.0-2.5 | 0.30-0.65 | 0.03 | 0.03 | 0.75 |
| Tensile Strength, ksi: | 80* |
| Yield Strength, ksi: | 55* |
| Elongation %: | 40* |
The AWS Class ER316/316H MIG and TIG filler wires are made from austenitic stainless steel consumables that contain chromium (around 16–18%), nickel (10–14%), and molybdenum (2–3%) to boost corrosion resistance. The 316H grade has a higher carbon content, which enhances its strength at elevated temperatures. This unique composition offers excellent protection against pitting, crevice corrosion, and oxidation. Typically, the mechanical properties include good tensile strength, high ductility, and outstanding toughness. The weld deposits are known for their stable arc characteristics, smooth bead appearance, and strong resistance to hot cracking, even under demanding service conditions.
AWS Class ER316/316H MIG and TIG wires are commonly used for welding austenitic stainless steels in situations that require exceptional corrosion and heat resistance. They are frequently employed in the fabrication of chemical processing equipment, pressure vessels, heat exchangers, piping systems, and offshore structures. These wires are also well-suited for marine environments, pharmaceutical plants, and the food processing industry. The 316H grade is particularly effective in high-temperature applications, such as boilers and furnace components. They deliver clean, high-quality welds whether in shop fabrication or on-site work.
